Unparalleled Features
The 3500 uses OMR technology. This technology, partnered with the benefits listed below, create high-speed, dependable, and automatic test scanning.
-
1
-
Sheer Accuracy
With OMR technology, the 3500 model boasts nearly flawless accuracy with a margin of error of less than 1%.
-
2
-
Ease of Use
The 3500 is completely hands-off, so that you can concentrate on more pressing responsibilities.
-
3
-
Top-Notch Performance
Process 3,500 forms per hour, including full-page forms that have 48 columns, 109 lines, and 5232 markings.
-
4
-
Powerful Upgrades
Double the capacity by adding the duplex read head option that enables the Sekonic 3500 to read both sides of the form in one single pass.
-
5
-
Compatible with DataLink Ascend
Scan your data directly into DataLink Ascend, our cloud-based assessment management solution. Get better exam scoring, reporting, analysis, and communication.
The Sekonic 3500 Is Ideal for…
With fast and easy installation and unparalleled work performance, the Sekonic 3500 is designed for university officials, department heads, and administrative office managers.
If you need to process assessment information quickly and accurately, the Sekonic 3500 is one of the most powerful test scanners on the market.
Downloads
Sekonic 3500 Tech Specs
Read Head: | Single-sided read or Dual-sided read |
Document Transport: | Auto Feed/Hand Feed |
Speed: | 59 ppm / 3500 pph |
Channels: | 48 |
Automated Document Feeder (ADF): | 500 Forms |
Form Output Stacker: | 500 Forms |
Mark Discrimination: | 16 steps (256 Degrees) |
Mark Implements: | Pencil or Optional Pencil + Pen |
Mark Position: | 5,232 (per each page) |
Mark Shapes: | Rectangle, Ovals and Circles |
Calibration: | Automatic |
Utility Software (optional*): | DataLink Connect, Remark Classic OMR |
Printer: | Optional |
Bar Code Reader: | Optional |
PC & Mac Compatibility: | PC |
Min. Document Size: | 2.5” x 4.33” |
Max. Document Size: | 9” x 14” |
Scanner Dimensions (W x H x D): | 14” x 9” x 22.5” |
Scanner Weight: | 38 lbs |
